Features
  • Pocket type light and rugged
  • 3 1/2 L.C.D
  • Intrinsically Safe/Electro Chemical Sensor used
  • Available in PPM / Percentage
  • Available for O2%, O2 PPM, NH3, CO, SO2, H2S, NO, CL2, HCL, etc
 Power
  • 9V Alkaline Cell / 9V Adaptor
 Display
  • 3 1/2 Digit LCD / 4 1/2 Digit LCD
 Sampling
  • Diffusion mode / through Inlet & Outlet Connector
 Physical Dimension
  • 150mm X 80mm X 35mm for Pocket type
  • Weight less than 500 gms
  • 120mm X 71mm X 71mm for Panel-mounted
 Optional
  • Sampling system consisting of probe with In-built filter.
 External Controls
  • Span & Zero potentiometers
 Technical Specifications

Parameters
Range
Accuracy
Resolution
O2
0 to 25%
+/- 2% of Reading
0.1%
CO
0 to 1999
+/- 3% of Reading
1 ppm
SO2
0 to 1999
+/- 3% of Reading
1 ppm
NO
0 to 1000
+/- 3% of Reading
1 ppm
H2S
0 to 200
+/- 3% of Reading
1 ppm
NH3
0 to 200
+/- 3% of Reading
1 ppm
CL2
0 to 20 ppm
+/- 3% of Reading
0.1 ppm
NO2
0 to 200 ppm
+/- 3% of Reading
1 ppm
H2
0 to 2%
+/- 3% of Reading
0.01%
O2
0 to 100%
+/- 2% of Reading
0.01%
